What the shop can hold.
One row per process, with the limits Pacific Bending publishes for it. Where a process carries no published figure the row says on request, which is the honest answer rather than a guess.
01
The capability sheet
ProcessWhat it isPublished limit
Draw bendingMandrel tube and pipe bending on manual and NC machines, from a stock of hundreds of dies.3.5 in · 3.0 in · Hundreds, wide variety of bendsRoll bendingLarge radius bends for architectural and artistic work.Aluminum, steel, stainless steel · Large radiusTube flanging and flaringO-ring face seal, AN and JIC flaring for rigid hydraulic lines, with pickled pipe and JIC tubing in stock.-3 to -24 (3/16 in to 1 1/2 in outside diameter) · 37 and 90 · Pickled pipe and JIC tubing, various sizesPlasma and flame cuttingIn-house hi-definition plasma and twin-head flame cutting in mild steel, stainless, AR plate and aluminum.2.25 in · 8.00 in · 8 ft x 24 ft sheetsSaw cuttingSaw cutting out of material held in stock, so a job can start without waiting on an order.18.00 in x 20.75 in · Thousands of pounds in stockMachiningCNC and manual machining, with product modelling alongside the machine work.On requestFabricationMIG and TIG fabrication in stainless steel, steel and aluminum for forestry, construction, automotive, aerospace, military and mining, including OEM products.Stainless steel, steel, aluminum · MIG and TIG · Auto-saw cutting, iron working (punching, shearing), fly marking, bead rolling, plate rollingMedia blastingIn-house garnet blasting to a clean abrasive surface, which is what powder coat needs to adhere.GarnetPowder coatingHand coating over media blasting or a bio-friendly chemical wash, at the MIL thickness each product calls for.Wide variety · Available on request · MIL thickness per productPress brakePress braking, advertised by the shop on its process list.On requestFly markingFly marking, one of the shop’s in-house fabrication specialities.On request
